Fully Automatic L Sealer With Shrink Wrapping Machine

Send Inquiry

Request To Call Back

Fully Automatic L Sealer With Shrink Wrapping Machine

Name: Fully Automatic L Sealer With Shrink Wrapping Machine
Brand: INTERO PACTEC INDIA PVT LTD
Price: 450000 INR
Availability: InStock

Price 450000 INR/ Number

Get a Price/Quote

MOQ : 1 , , Number

Fully Automatic L Sealer With Shrink Wrapping Machine Specification

Type
Fully Automatic L Sealer with Shrink Wrapping Machine

Material
Mild Steel Body with Powder Coated Finish

Capacity
Up to 1500 packs per hour

Computerized
Yes

Automatic Grade
Fully Automatic

Control System
PLC Controlled HMI Panel

Shrink Speed
Adjustable up to 25 m/min

Air Pressure
6 Bar (Min)

Roll Diameter
Up to 300 mm

Voltage
220-240V, 50/60Hz

Dimension (L*W*H)
2000 mm x 800 mm x 1600 mm

Weight
Approx. 350 kg

Color
Blue & Grey

Application
Bottles, Boxes, Electrical Components, Stationery, Food Products

Sealing Type
L-Type Impulse Sealing

Safety Features
Emergency Stop Button, Overload Protection, Safety Guards

Cooling System
Integrated Cooling Fan

Max Packing Size
450 mm x 350 mm x 150 mm

Operating Temperature
120C to 200C Adjustable

Heating Power
7.5 kW

Installation
Floor Mounted, Easy to Set Up

Packaging Length
80 mm to 400 mm (Variable)

Brand Compatibility
Compatible with Standard Shrink Film Rolls

Noise Level
75 dB

Machine Structure
Heavy Duty Robust Construction

Conveyor Type
Mesh Belt Conveyor with Variable Speed

Film Used
PVC / POF / Polyolefin Heat Shrink Film

Fully Automatic L Sealer With Shrink Wrapping Machine Trade Information

Minimum Order Quantity
1 , , Number

Payment Terms
Cash in Advance (CID), Cheque

Supply Ability
10 Per Month

Delivery Time
5 Days

Main Domestic Market
Pondicherry, South India, Karnataka, Tamil Nadu, Kerala

About Fully Automatic L Sealer With Shrink Wrapping Machine

Fully Automatic L Sealer With Shrink Wrapping Machine is extensively used in industries such as foodstuff, cosmetics, printing, pharmacy, software, flooring, ceramics and beverage. Owing to its sturdiness, durability and high tensile strength, this L-Sealer Cum Tunnel is offered to clients in varied specifications. It is manufactured by using high quality material and cutting edge technology as per the set industry standards. Apart from this, we provide this Fully Automatic L Sealer With Shrink Wrapping Machine to our patrons in the stipulated time to meet the market demand

Precision and Performance

Engineered for seamless packaging automation, this L Sealer utilizes a mesh belt conveyor and impulse sealing system, allowing for secure, consistent seals across a wide variety of product shapes and sizes. With an adjustable shrink speed of up to 25 meters per minute and computerized PLC controls, operators maintain precise command over every parameter, ensuring perfect results each cycle.

Versatility and Applications

This machine accommodates diverse packaging needs-handling bottles, boxes, electronic components, foodstuffs, and stationary-with film compatibility for PVC, POF, or polyolefin. Variable packaging lengths from 80 mm to 400 mm, along with adaptability for film rolls up to 300 mm diameter, create flexibility for different product ranges and industries. Integrated cooling and safety systems provide smooth, safe operation in demanding settings.

Ease of Use and Maintenance

Setup is simple and floor installation is straightforward, while the color-coded PLC HMI panel offers intuitive controls. Safety guards, emergency stop, and overload protection are standard, ensuring operator safety. The robust, powder-coated mild steel construction enhances durability, making the machine suitable for continuous operation in production and export environments.

FAQ's of Fully Automatic L Sealer With Shrink Wrapping Machine:

Q: How does the Fully Automatic L Sealer with Shrink Wrapping Machine operate?

A: The machine employs an L-type impulse sealing system and a mesh belt conveyor to automatically feed, seal, and shrink-wrap products using heat (at 120C to 200C, adjustable). Operators can easily control the process using the PLC-controlled HMI panel, adjusting speed, temperature, and packaging length as needed.

Q: What types of films and products can this machine handle?

A: It is compatible with PVC, POF, and polyolefin heat shrink films, and it can wrap bottles, boxes, electrical components, stationery items, and food products, making it versatile for various industry applications.

Q: When should I use this machine in my production line?

A: This fully automatic sealer is best used where high-speed, consistent packaging is required, such as in medium to large-scale manufacturing, warehousing, or export settings that demand up to 1500 packs per hour with minimal manual intervention.

Q: Where can this machine be installed, and how?

A: It is designed as a floor-mounted system, making installation straightforward in industrial packaging zones or factories. Its robust, heavy-duty construction and powder-coated finish ensure longevity and reliable operation under continuous use.

Q: What is the packaging process with this machine?

A: Products are placed onto the mesh belt conveyor, which transports them to the sealing area. The machine forms an L-shaped seal, cuts the shrink film, and automatically moves the product into the heat tunnel. The integrated cooling fan sets the film for a snug, finished package.

Q: How does the integrated safety system benefit operators?

A: The machine is equipped with safety guards, an emergency stop button, and overload protection to minimize risks during operation, thus fostering a secure working environment and reducing the likelihood of accidents.

Q: What are the key advantages of choosing this L Sealer and Shrink Wrapping Machine?

A: Key benefits include high throughput, film versatility, easy computerized controls, reliable operation, advanced safety systems, and compatibility with industry-standard shrink film rolls-making it an efficient, cost-effective solution for diverse packaging needs.
